BIOABSORBABLE PIN
£47.00
– Bioabsorbable Pin designed for traumatic joint and small bone fractures.
– Constructed from PLGA + TCP biocomposite, enhancing compatibility and safety.
– Offers a unique product with multiple size options for varied surgical needs.
– Easy implementation with detailed instruction manuals for each diameter.
– Pins are capable of being absorbed and replaced by bone over time.
– Available in sizes: Ø1.3 mm, Ø1.7 mm, Ø2 mm, Ø2.3 mm, and Ø3 mm.
– REF codes for easy identification: BAP19010225, BAP19010240, BAP19010325, BAP19010340, BAP19011312, BAP19011720.
– Ideal for orthopedic applications and minimally invasive procedures.
– Ensures stronger fixation and faster recovery in patients.
Bioabsorbable Pin
Advanced biocomposite fixation for traumatic joint and small bone fractures. Engineered from PLGA + TCP biocomposite material, these pins provide secure fixation while naturally resorbing and being replaced by bone over time, eliminating the need for removal surgery.
Clinical overview
The Bioabsorbable Pin is specifically designed for the fixation of traumatic joint fractures and small bone fractures and deformities. Its PLGA + TCP biocomposite structure provides superior biocompatibility and mechanical stability while maintaining the unique advantage of gradual bioresorption. Unlike traditional metallic implants, these pins are progressively replaced by natural bone tissue, eliminating the need for secondary removal procedures and reducing patient morbidity.
Available in six distinct configurations with diameters ranging from 1.3 mm to 3 mm and lengths from 12 mm to 40 mm, the Bioabsorbable Pin accommodates diverse surgical needs in shoulder and sports medicine applications. Each size is supplied with comprehensive instruction manuals, ensuring straightforward implementation and optimal clinical outcomes in minimally invasive procedures.
Key features & surgeon benefits
Advanced Material Composition
- PLGA + TCP biocomposite ensures optimal tissue integration
- Gradual resorption aligned with bone healing timeline
- Eliminates foreign body reactions and chronic inflammation
Simplified Implementation
- Six size options for varied fracture patterns and anatomies
- Detailed instruction manuals provided for each diameter
- Compatible with standard orthopedic instrumentation
Cost-Effective Fixation
- Eliminates secondary removal surgery costs
- Reduces overall treatment duration and hospital stays
- Competitive pricing without compromising quality
Tailored Solutions
- Multiple diameter and length combinations available
- OEM customisation options for specific clinical protocols
- Batch and volume pricing available
Technical specifications
| Indications | Traumatic joint fractures, small bone fractures, deformities; shoulder and sports medicine |
|---|---|
| Sizes / range | Ø1.3 mm, Ø1.7 mm, Ø2 mm, Ø2.3 mm, Ø3 mm; lengths 12–40 mm |
| Material | PLGA + TCP Biocomposite |
| Sterilisation | As applicable |
| Packaging | Individual sterile packaging with instruction manual per diameter |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| 1 | BaPin – Ø2 mm × L25 mm (REF: BAP19010225) | 1 |
| 2 | BaPin – Ø2 mm × L40 mm (REF: BAP19010240) | 1 |
| 3 | BaPin – Ø3 mm × L25 mm (REF: BAP19010325) | 1 |
| 4 | BaPin – Ø3 mm × L40 mm (REF: BAP19010340) | 1 |
| 5 | BaPin Mini – Ø1.3 mm × L12 mm (REF: BAP19011312) | 1 |
| 6 | BaPin Mini – Ø1.7 mm & Ø2.3 mm × L20 mm (REF: BAP19011720) | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss your orthopedic fixation requirements, request samples, or arrange a product demonstration. We offer competitive pricing, volume discounts, and rapid delivery.
