Benchtop High or Low Speed Large Capacity Centrifuge NEUHC46
£6,621.50£7,990.00 (-17%)
– High or low-speed operation for versatile separation needs
– Maximum speed of 22,000 rpm for efficient performance
– Large capacity with swing rotor accommodating 4 x 750ml containers
– Microprocessor control for precise operation and monitoring
– Colorful touch panel for user-friendly interface
– Enhanced safety features with protections against overspeed and imbalance
– LCD digital display for clear error alerts and operational feedback
– Low noise operation at <65dB(A) for a quieter workspace
– Temperature range from -20℃ to +40℃ with accuracy of ±1℃
– Compact design with dimensions of 520x720x420mm for benchtop use
Benchtop High or Low Speed Large Capacity Centrifuge NEUHC46
Versatile benchtop centrifuge combining high-speed (22,000 rpm) and low-speed separation with large 4 × 750 ml capacity. Microprocessor-controlled with colorful touch panel, advanced safety features, and quiet operation—ideal for clinical, diagnostic, and research laboratories.
Clinical overview
The NEUHC46 is a dual-speed benchtop centrifuge engineered for high-throughput clinical and diagnostic laboratories. With maximum speed of 22,000 rpm and maximum RCF of 34,700 × g, it efficiently separates blood components, serum, plasma, and other biological samples. The large 4 × 750 ml swing rotor capacity enables processing of multiple samples simultaneously, reducing turnaround time and improving laboratory productivity.
Microprocessor control with advanced safety interlocks—overspeed protection, over-temperature monitoring, imbalance detection, and automatic electronic/mechanical locking—ensures operator safety and equipment longevity. The colorful touch panel and LCD digital display provide intuitive operation and real-time error alerts, while brushless frequency conversion motor technology eliminates carbon dust contamination and reduces maintenance requirements.
Key features & surgeon benefits
Dual-Speed Separation
- High-speed operation up to 22,000 rpm for rapid separation
- Low-speed capability for gentle sample handling
- Maximum RCF of 34,700 × g for efficient pelleting
Large Capacity & User-Friendly Interface
- 4 × 750 ml swing rotor for high-throughput processing
- Colorful touch panel with intuitive controls
- Programmable timer up to 9 hours 59 minutes
Advanced Protection Systems
- Overspeed, over-temperature, and imbalance protection
- Automatic electronic and mechanical locking
- LCD error alerts and operational feedback
Quiet, Clean Operation
- Low noise output <65 dB(A) for comfortable workspace
- Brushless frequency conversion motor—no carbon dust
- Compact benchtop design: 520 × 720 × 420 mm
Technical specifications
| Model | NEUHC46 (MSLHC46) |
|---|---|
| Maximum Speed | 22,000 rpm |
| Maximum RCF | 34,700 × g |
| Rotor Type | Swing rotor, 4 × 750 ml capacity |
| Speed Accuracy | ±20 rpm |
| Temperature Range | −20 °C to +40 °C |
| Temperature Accuracy | ±1 °C |
| Timer Range | 0–9 hours 59 minutes |
| Motor | Microprocessor-controlled AC frequency conversion motor (brushless) |
| Noise Level | <65 dB(A) |
| Power Supply | AC 220 V or 110 V, 50–60 Hz, 18 A |
| Dimensions | 520 × 720 × 420 mm (W × H × D) |
| Weight | 95 kg |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Centrifuge Unit | NEUHC46 benchtop centrifuge with microprocessor control | 1 |
| Swing Rotor | 4 × 750 ml capacity rotor with buckets | 1 |
| Power Cord | AC power supply cable (220 V or 110 V) | 1 |
| User Manual | Operation and maintenance guide | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss your laboratory’s centrifugation requirements, request a detailed quote, or arrange a product demonstration. We offer flexible delivery and customisation options to meet your facility’s needs.
