Nucleic Acid Extractor NEUNAE01
£16,991.50£21,990.00 (-23%)
– High-capacity nucleic acid extractor with a processing volume of 30-1500μl.
– Accommodates 15, 32, or 48 samples per run, customizable based on requirements.
– Achieves a magnetic particle collection efficiency of ≥95%.
– Offers multi-mode and multi-speed processing for varied application needs.
– Compatible with reagents suitable for Magnetic Particle Method.
– User-friendly interface featuring a Chinese/English touch-control operating system.
– Stores up to 15 preinstalled protocols with unlimited capacity on pad for protocol management.
– Equipped with UV light for effective pollution control.
– Supports USB computer interface and optional Ethernet network communication.
– Dimensions: 440mm(W) x 435mm(L) x 445mm(H); Weight: 31.5kg; Power: 600W.
Specifications
Processing Volume:30 -1500μl，30-1000ul Capacity:15,32,48 samples per run customized Collection efficiency of the magnetic particles:≥95% Heating Temperature(Not suitable for 48samples per run): For cell lysis, Room temperature to 120℃; For nucleic acid elution, Room temperature to 120℃ Processing-mode: Multi-mode, multi-speed available Reagents: Reagents suitable for Magnetic Particle Method Operation Interface: Chinese/English-Language Operating System, Touch-control Operation Storage Capacity:15 preinstalled protocols in main unit, unlimited in pad Protocol Management: Create, edit, delete, protocol mode Pollution control: UV light Computer Interface: USB Network Communication: Ethernet(optional) Dimensions:440mm（W）×435mm（L）×445mm（H） Weight:31.5kg Power Requirements:AC110±10%/230V±10%, 50Hz/60H±1Hz, 600W Temperatures allowed during operation:10-40℃ Relative humidity allowed during operation:<80%
|
ITEMS
|
PARAMETER
|
|
Processing Volume
|
30 -1500μl,30-1000ul
|
|
Sample Capacity
|
15,32,48 samples per run customized
|
|
Collection efficiency of the magnetic particles
|
≥95%
|
|
Processing-mode
|
Multi-mode, multi-speed available
|
|
Reagents
|
Reagents suitable for Magnetic Particle Method
|
|
Operation Interface
|
Chinese/English-Language Operating System, Touch-control Operation
|
|
Storage Capacity
|
15 preinstalled protocols in main unit, unlimited in pad
|
|
Protocol Management
|
Create, edit, delete, protocol mode
|
|
Pollution control
|
UV light
|
|
Computer Interface
|
USB
|
|
Network Communication
|
Ethernet(optional)
|
|
Dimensions
|
440mm(W)×435mm(L)×445mm(H)
|
|
Weight
|
31.5kg
|
|
Power Requirements
|
AC110±10%/230V±10%, 50Hz/60H±1Hz, 600W
|
|
Temperatures allowed during operation
|
10-40℃
|
|
Relative humidity allowed during operation
|
<80%
|
