Portable Bone Density Scanner NEUBD10
£4,790.00£4,950.00 (-3%)
– Portable and lightweight design for easy transport
– Utilizes ultrasound technology for non-invasive bone density measurement
– Measures bone density at the radius and tibia, suitable for all ages
– Ideal for pregnant women, children, and the elderly
– Provides reliable results unaffected by soft tissue thickness or bone size
– Quick measurement time: single measurement in ≤ 25 seconds
– Compatible with Windows XP and above operating systems
– Features a comprehensive database for multi-age data selection
– Operating conditions: 5-40℃ and relative humidity ≤ 80%
– Easy to connect to desktop computers, laptops, or tablets
Portable Bone Density Scanner NEUBD10
Product Features
NEUBD09-NEUBD10 use the ultrasound to measure the Radius and Tibia bone density, the measurement process is no wound, especially suitable for pregnant women, children and other special populations.
Suitable for all kinds of medical and physical examination institutions, it can provide detailed measurement data for the elderly osteoporosis and the development of children bone density.
Light and portable
The product appearance is small and elegant, easy to carry, can link desktop computer, laptop or tablet.
Convenient
Measurement position is radius (or tibia), it is very convenient and easy to use.
Result reliable
The measurement results are not affected by soft tissue thickness, bone size, and skeletal shape.
Wide applicability
Including Asia, Europe and other region database, multi-age data can be chose
| Measurement position | Radius (NEUBD09-NEUBD10) |
| Measurement theory | Critical Angle Side Wave Theory |
| Ultrasound Parameters | SOS, T-score |
| Other parameters | T-score, Z-score, Skeletal age, BQI, RRF, EOA |
| Probe frequency | 1MHz±15% |
| Measure time | Single ≤ 25s, Repettion ≤ 75s |
| Operation system | windows XP or above |
| Operating temperature | 5-40℃ |
| Operating humidity | Relative humidity ≤ 80% |
| Power requirement | AC220V±10%,50Hz±1Hz |
| Suitable population | Pregnant women, Baby, Children, The elderly |
