Diagnostic Ultrasound Scanner for Vet NEUVU24
£1,695.75£2,390.00 (-29%)
– Advanced Diagnostic Ultrasound Scanner for veterinary use (NEUVU24)
– Accurate pregnancy detection in pigs as early as 18 days post-mating
– Features B, 2B, 4B, B/M, M display modes for versatile imaging
– High-resolution 5.7″ LED display ensures clear visuals even outdoors
– Permanent image storage for up to 100 frames with USB support
– Dual power supply with high-capacity lithium battery lasting over 6 hours
– Eight internal pseudo colors for enhanced image differentiation
– Capability to diagnose sow reproductive disturbances (e.g., Pyometra)
– Compact design with a net weight of only 1.1kg for easy portability
– Equipped with advanced measuring functions for accurate fetal assessments
Diagnostic Ultrasound Scanner for Vet NEUVU24
Advanced portable ultrasound system for comprehensive veterinary diagnostics across multiple species. Early pregnancy detection in swine as early as 18 days post-mating with extended battery life and outdoor-optimized display.
Clinical overview
The NEUVU24 represents a breakthrough in portable veterinary diagnostic imaging, combining advanced ARM7 embedded control systems with practical field portability. This system enables veterinarians and farm managers to perform accurate pregnancy detection as early as 18 days post-mating in swine—approximately 12 days earlier than traditional methods—resulting in direct cost savings of approximately $1,000 per 100 sows through early identification of non-pregnant animals and reduced feed waste.
Engineered for multi-species veterinary applications, the NEUVU24 supports comprehensive diagnostic imaging for bovine, canine, equine, feline, swine, ovine, goat, and llama patients. The system features 5 display modes (B, 2B, 4B, B/M, M), intelligent TGC control, 256 gray scale levels, and extensive measurement capabilities including obstetric calculations, cardiac assessments, and general anatomical quantification. With dual power supply options, over 6 hours of battery operation, and a high-resolution 5.7-inch LED display optimized for outdoor visibility, the NEUVU24 delivers professional-grade diagnostic performance in a compact 1.1kg package suitable for both clinical and field environments.
Key features & surgeon benefits
Pregnancy Diagnosis at 18 Days
- Detect pregnancy in swine 12 days earlier than traditional methods
- Save approximately $1,000 per 100 sows in feed costs
- Identify non-pregnant animals for rapid management decisions
Ultra-Lightweight Field Design
- Weighs only 1.1kg with compact 212×154×58mm dimensions
- Over 6 hours battery life on high-capacity lithium battery
- Includes protective leather case and soft rubber coat for transport
Professional Display & Processing
- 5.7″ high-resolution LED display optimized for outdoor visibility
- 8 pseudo-color options with 256 gray scale levels
- Dynamic range 27-90dB with intelligent TGC control
Multi-Species Capability
- 27 body marks across 7 categories for diverse species
- Species-specific OB measurements for 8 animal types
- Cardiac, general, and obstetric measurement protocols
Technical specifications
| Indications | Pregnancy detection, fetal assessment, reproductive disorder diagnosis (pyometra, mucometra), cardiac evaluation, general diagnostic imaging |
|---|---|
| Sizes / range | Display: 5.7″ LED; Probe: 3.5MHz mechanical sector; Depth: 200mm maximum; Storage: 100 frames internal |
| Material | Aluminum alloy main unit; waterproof mechanical sector probe; protective leather case and soft rubber coat included |
| Sterilisation | Waterproof probe design; standard veterinary cleaning and disinfection protocols; not autoclavable |
| Packaging | Black plastic suitcase with leather carrying case, green soft rubber protective coat, adjustable sunshine cover (A, B, C sections) |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Main Unit | NEUVU24 ultrasound system with ARM7 embedded control | 1 |
| Probe | 3.5MHz waterproof mechanical sector probe | 1 |
| Power Adapter | AC 110/230V self-adapting power supply | 1 |
| Battery | High-capacity lithium battery 5200mAh (over 6 hours operation) | 1 |
| Carrying Case | Leather carrying case for portable transport | 1 |
| Protective Coat | Green soft rubber protective coat | 1 |
| Sunshine Cover | Adjustable sunshine cover (A, B, C sections) | 1 |
| Storage Case | Black plastic suitcase for system storage | 1 |
| Base Charger | Battery charging dock | 1 |
| Accessories | Belt, probe socket, spatula, USB connectivity cable | 1 set |
Get in touch for pricing & availability
Contact our sales team to discuss the NEUVU24 system specifications, pricing, delivery timelines, and customization options for your veterinary practice or agricultural operation.
Email: info@neuvar.co.uk
