Handheld Ultrasound Machine NEUPU67
£2,507.50£3,790.00 (-34%)
– Portable Handheld Ultrasound Machine (Model NEUPU67)
– Scanning mode: Electronic array for diverse applications
– Convex probe for Abdomen, Gynecology, Obstetrics, Cardiac, and Urology
– Linear probe for Thyroid, Pediatrics, Vascular, Carotid, Breast, and MSK
– Display modes: B, B/M, color, PW, and PDI
– Frequency range: Convex (3.5MHz/5MHz), Linear (7.5MHz/10.0MHz)
– Depth capabilities: Convex (90mm-305mm), Linear (20mm-100mm)
– Long battery life: Up to 3 hours of continuous use
– Lightweight and compact design: Dimensions 156×60×20mm, weight 270g
– Wi-Fi connectivity: 802.11g/20MHz/2.4G for easy data transfer
Handheld Ultrasound Machine NEUPU67
Compact, portable ultrasound system with dual-probe capability and multi-modal imaging. Delivers real-time B, B/M, color, PW, and PDI modes across abdominal, cardiac, obstetric, vascular, and musculoskeletal applications. Extended battery life and wireless connectivity for seamless clinical integration.
Clinical overview
The NEUPU67 is a fully portable handheld ultrasound platform engineered for point-of-care diagnostics across multiple clinical specialties. Its electronic array scanning technology and dual-probe configuration enable comprehensive imaging from superficial structures to deep abdominal and cardiac anatomy. The system supports five display modes—B, B/M, color, pulsed-wave (PW), and power Doppler imaging (PDI)—providing clinicians with versatile diagnostic capability in a device weighing just 270 grams.
Designed for high-volume clinical environments, the NEUPU67 delivers up to 3 hours of continuous operation on a single charge, with integrated Wi-Fi connectivity (802.11g/2.4GHz) for rapid image transfer and remote consultation. The compact form factor (156×60×20mm) and intuitive interface make it ideal for emergency departments, intensive care units, mobile clinics, and specialist outpatient settings where rapid, reliable imaging is essential.
Key features & surgeon benefits
Dual-Probe Multi-Specialty Imaging
- Convex probe for deep abdominal, cardiac, obstetric, and urological imaging
- Linear probe for superficial structures: thyroid, breast, vascular, and musculoskeletal
- Frequency range optimised for each application (3.5–10.0MHz)
Rapid Point-of-Care Deployment
- Lightweight (270g) and compact (156×60×20mm) for bedside and mobile use
- 3-hour battery life supports extended clinical sessions without recharging
- Wi-Fi connectivity enables instant image sharing and remote consultation
Cost-Effective Multi-Modal Imaging
- Single platform replaces multiple dedicated ultrasound systems
- Reduced capital expenditure and maintenance overhead
- Scalable deployment across departments and remote facilities
Flexible Integration & OEM Support
- Modular probe design allows future expansion and upgrades
- Wireless protocol compatibility with existing hospital networks
- Custom firmware and preset configurations available for specialised workflows
Technical specifications
| Indications | Abdomen, Gynecology, Obstetrics, Cardiac, Urology, Thyroid, Pediatrics, Vascular, Carotid, Breast, Musculoskeletal |
|---|---|
| Scanning mode | Electronic array |
| Display modes | B, B/M, Color, PW, PDI |
| Convex probe frequency | 3.5MHz / 5.0MHz |
| Linear probe frequency | 7.5MHz / 10.0MHz |
| Convex depth range | 90–305mm |
| Linear depth range | 20–100mm |
| Battery life | Up to 3 hours continuous use |
| Dimensions | 156 × 60 × 20mm |
| Weight | 270g |
| Wireless connectivity | 802.11g / 20MHz / 2.4GHz |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Main unit | NEUPU67 handheld ultrasound console with integrated display and controls | 1 |
| Convex probe | Electronic array probe, 3.5MHz/5.0MHz, for abdominal, cardiac, obstetric, and urological imaging | 1 |
| Linear probe | Electronic array probe, 7.5MHz/10.0MHz, for thyroid, vascular, breast, and musculoskeletal imaging | 1 |
| Battery pack | Rechargeable lithium-ion, 3-hour runtime | 1 |
| USB charging cable | Standard micro-USB for battery charging and data transfer | 1 |
| Protective carrying case | Padded hard case for transport and storage | 1 |
| Ultrasound gel | Hypoallergenic coupling gel, 250ml bottle | 1 |
| Quick-start guide | Multi-language user manual and clinical reference | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss pricing, volume discounts, and customisation options for the NEUPU67. We offer flexible delivery schedules and comprehensive training support for your clinical team.
