Total Dental Care Diode Laser Machine NEUDLS02
- Advanced Total Dental Care Diode Laser Machine (Model: NEUDLS02)
- Supports two wavelengths: 980nm and 810nm for versatile applications
- Adjustable output power: 0.1W-10W (MSLDLS02A) and 0.1W-7W (MSLDLS02B)
- Multiple operation modes: Continuous Wave, Single, and Repeat
- User-friendly color LCD touch screen interface
- Compact size: 265 mm x 200 mm x 210 mm and lightweight at 3 kg
- Air cooling system for efficient thermal management
- High safety classification: Class I Type B
- Designed for optimal operating conditions: 10℃ to 40℃
- Waterproof footswitch with IPX8 rating for enhanced protection
- SKU
- NEUDLS02
- Brand
- MedGroup
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Total Dental Care Diode Laser Machine NEUDLS02
Advanced dual-wavelength semiconductor diode laser system engineered for comprehensive dental applications. Delivers precise, controlled energy at 980nm and 810nm with adjustable power output, intuitive touch-screen interface, and robust safety features for clinical excellence.
Clinical overview
The NEUDLS02 is a versatile, clinically proven diode laser system designed for modern dental practices. Its dual-wavelength capability (980nm and 810nm) enables practitioners to select the optimal wavelength for specific tissue interactions, from precise soft tissue ablation to deep hemostatic penetration. The system's variable power output (0.1W–10W depending on model) and multiple operation modes—Continuous Wave, Single pulse, and Repeat—provide granular control over energy delivery, minimizing thermal damage and enhancing clinical outcomes.
Built for efficiency and safety, the NEUDLS02 features a color LCD touch-screen interface for intuitive operation, air-cooling technology for sustained performance, and comprehensive safety classification (Class I Type B). The compact footprint (265 × 200 × 210 mm) and lightweight design (3 kg) make it ideal for space-constrained operatories, while the IPX8-rated waterproof footswitch ensures reliability in wet clinical environments.
Key features & surgeon benefits
Dual-Wavelength Technology
- 980nm for enhanced soft tissue cutting and hemostasis
- 810nm for deeper tissue penetration and alternative applications
- Single system eliminates need for multiple laser platforms
Intuitive Operation & Control
- Color LCD touch-screen interface for rapid parameter adjustment
- Three operation modes: CW, Single pulse, and Repeat for procedural flexibility
- Adjustable pulse width (25μs–10s) for precision energy delivery
Compact & Cost-Effective
- Lightweight (3 kg) and compact (265 × 200 × 210 mm) for easy placement
- Air-cooling system reduces maintenance and operational costs
- Efficient power consumption with regulated 15V power supply
Clinical-Grade Safety Standards
- Class I Type B safety classification for regulated environments
- IPX8-rated waterproof footswitch for wet operatory conditions
- 650nm aiming beam (4mW max) for precise targeting and reduced collateral damage
Technical specifications
| Laser Type | Semiconductor diode laser |
|---|---|
| Wavelengths | MSLDLS02A: 980nm ±10nm; MSLDLS02B: 810nm ±10nm |
| Output Power | MSLDLS02A: 0.1W–10W; MSLDLS02B: 0.1W–7W |
| Operation Modes | Continuous Wave (CW), Single pulse, Repeat |
| Pulse Width | 25μs–10s or continuous |
| Fiber Core Size | ≥200µm (SMA 905 connector) |
| Numerical Aperture | NA = 0.22–0.48 |
| Aiming Beam | 650nm ±10nm diode laser, 4mW max, adjustable brightness |
| Laser Class | Class 4 |
| Control Interface | Color LCD touch screen |
| Power Supply | Input: 100–110V/240Vac, 1.4–0.7A, 47–63Hz; Output: 15V, 6.79A max |
| Cooling System | Air cooling |
| Safety Classification | Class I Type B |
| Dimensions | 265mm (H) × 200mm (W) × 210mm (D) |
| Weight | 3 kg |
| Operating Temperature | 10°C–40°C (recommended 10–35°C for optimal heat dissipation) |
| Storage/Transport Temperature | −20°C to +50°C |
| Operating Humidity | 30%–60% |
| Storage/Transport Humidity | 10%–80% |
| Device Waterproof Rating | IPX1 |
| Footswitch Waterproof Rating | IPX8 |
| Warranty | 2 Year Manufacturer Warranty |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Main Laser Unit | NEUDLS02 semiconductor diode laser console with color LCD touch-screen interface | 1 |
| Fiber Optic Delivery System | SMA 905 connector, ≥200µm core, adjustable NA (0.22–0.48) | 1 |
| Aiming Beam Module | 650nm diode laser, 4mW max, adjustable brightness | 1 |
| Waterproof Footswitch | IPX8-rated pedal control for hands-free operation | 1 |
| Power Supply Unit | FSP105-KGAM1, 100–110V/240Vac input, 15V/6.79A output | 1 |
| Power Cord | Mains cable with regional plug adapter | 1 |
| User Manual | Comprehensive operating and safety documentation | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss system configuration, pricing, and delivery timelines. We offer flexible ordering options, OEM customization, and comprehensive clinical support.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
